Per Expander Machine

Material weight measure section takes special measuring controlling device and loading device ,they are controlled by PLC and HMI ,the amount can be controlled accurately, Welcome to buy the Pinsheng® Per Expander Machine from us.Ningbo PinSheng Machinery Manufacturer as one ofprofessional PRE EXPANDER MACHINE in China,we make the high quality PRE EXPANDER MACHINE

Send Inquiry    PDF DownLoad

Product Description

The Pinsheng® Per Expander Machine

Ningbo Pinsheng Machinery Co.,ltd is Per Expander Machine manufacturers and suppliers in China who can wholesale Per Expander Machine. We can provide professional service and better price for you. If you interested in Per Expander Machine products, please contact with us. We follow the quality of rest assured that the price of conscience, dedicated service.


Per Expander Machine Introduction.

Pinsheng  Model:PSPEB

Brand: PinSheng


1.1Steam system:

Accurate pressure reducer and PID control system (proprotional steam valve system)to keep very stable and accurate steam ,ensure material varia-tion.


1.2Pressure control:

Pressure sensor with multi-steam exhausting system to keep expansion chamber pressure stable,as well as reduces the steam consumption.


1.3Fillng system:

Set filling weight in HMI and electronic weighing filling to realize silling accurately and automatically .


1.4Material level control:

Adopts laser sensor to control the expansion level.

The temperature sensor and compressedair proprtional valve maintains accurate expansion


1.5 temperature control system

temperature which is suitable for highdensity expansion ,resulting in less broken beads.

Item

Unit

PSPEB-N110

PSPEB-N150

Expansion Chamber

Diameter

mm

∅1100

∅1500

Volume

0.9

3.2

Steam

Inlet

mm

∅40

∅50

Consumption

kg/cycle

8-11

15-18

Pressure

Mpa

0.6-0.8

0.6-0.8

Compressed air

Inlet

mm

∅25

DN40

Consumption

m³/cycle

0.5-0.6

0.5-0.6

Pressure

Mpa

0.6-0.8

0.6-0.8

Drainage

Blower outlet

mm

∅80

∅100

The total emission

mm

∅80

∅150

Connected load

Installing power

Kw

16

25

Density

g/L

12-30

12-30

Overall size (LXWXH)

mm

5600X3800X4500

6500X4100X5400

Weight

kg

3500

5000

Room height required

mm

5000

6000

Productivity

12g/L

kg/h

240

600

15g/L

kg/h

320

900

20g/L

kg/h

430

1200

30g/L

kg/h

600

1500

Secend Expansion

80-1000m³/h
